Aerial - Electric/ Hybrid Boom

Working Height: 12.00 m (≈ 39 ft 4 in)

Platform Height: 10.00 m (≈ 32 ft 10 in)

Horizontal Reach: 5.57 m (≈ 18 ft 3 in)

Up-and-Over Clearance: 4.28 m (≈ 14 ft 1 in)

Platform Capacity: 200 kg (≈ 440 lbs)

Platform Size: 0.76 m × 1.17 m (2 ft 6 in × 3 ft 10 in)

Stowed Dimensions:
 • Length: 4.17 m (≈ 13 ft 8 in)
 • Width: 1.50 m (≈ 4 ft 11 in)
 • Height: 1.98 m (≈ 6 ft 6 in)

Wheelbase: 1.90 m (≈ 6 ft 3 in)

Ground Clearance (Center): 0.15 m (≈ 6 in)

Drive Speed (Stowed): 5.2 km/h (≈ 3.2 mph)

Gradeability: 30 %

Turning Radius (Inside): 1.90 m

Turntable Rotation: 400° non-continuous

Power / Drive:
 • 48 V DC electric drive (three-phase AC motors)
 • Battery-powered; deep-cycle battery pack

Hydraulic Tank Capacity: 20.8 L

Weight: 3,665 kg

Units available for immediate rental across Saudi Arabia and the GCC

Maintained under Dayim’s preventive maintenance program

Inspected, tested, and certified prior to dispatch

Supported by Dayim’s 24/7 service, logistics, and technical teams

Available for short-term, long-term, and project-based rental contracts

Indoor facility and warehouse maintenance

Exterior building and façade work

Electrical, HVAC, and lighting installation

Retail, showroom, and commercial interior work

Signage, display, and ceiling applications

Work in restricted access zones and tight spaces

Working Height: 14.29 m (46 ft 4 in)

Platform Height: 12.29 m (40 ft 4 in)

Platform Capacity: 136 kg (300 lbs)

Stowed Height: 2.78 m (9 ft 1.5 in)

Machine Width: 0.74 m (2 ft 5 in)

Machine Weight: ≈ 472 kg (1,040 lbs)

Features / Design:
 • Tilt-back frame for easy loading through doorways
 • Small outrigger footprint
 • Durable Genie mast construction
 • Simple one-person operation
 • Versions with AC, DC, or battery drive

Units available for immediate rental across Saudi Arabia and the GCC

Maintained under Dayim’s preventive maintenance program

Inspected, tested, and certified before dispatch

Supported by Dayim’s 24/7 service, logistics, and technical teams

Offered for short-term, long-term, and project-based rental contracts

Indoor facility maintenance and servicing

Tight-access installations or repair works

Lighting, electrical, or HVAC access

Retail, commercial, or institutional environments

Shop floors, warehouses, showrooms

Projects requiring vertical access in compact spaces

Working Height: 20.16 m (≈ 65 ft 7 in)

Platform Height: 18.16 m (≈ 59 ft 7 in)

Horizontal Reach: 11.15 m (≈ 36 ft 7 in)

Up-and-Over Clearance: 7.39 m (≈ 24 ft 3 in)

Below-Ground Reach: 2.46 m (≈ 8 ft 1 in)

Platform Capacity (Unrestricted): 227 kg (≈ 500 lbs)

Platform Dimensions: 2.44 m × 0.91 m

Platform Rotation: 160°

Jib / Articulation: 1.52 m jib with 135° vertical rotation

Turntable Rotation: 355° non-continuous

Drive Speed (Stowed): 6.44 km/h

Drive Speed (Raised): 1.10 km/h

Gradeability: 45 %

Tire Contact Pressure: ~ 483 kPa

Weight (Electric mode): ~ 7,530 kg

Weight (Hybrid mode): ~ 7,756 kg

Fuel Tank Capacity: 64 L

Hydraulic Tank Capacity: 68.1 L

Sound Levels (Ground / Platform): 70 dB(A) in electric mode; 77 dB(A) in hybrid mode at ground

Power / Drive System:
 • Drive: 34V 3-phase AC
 • Battery Pack (Electric): 48V DC, 390 Ah (FLA)
 • Battery Pack (FE / Hybrid): 48V DC, 415 Ah (AGM)
 • Engine (for hybrid mode): Kubota D1105, 24.8 HP

Chassis & Features:
 • 4WD with active oscillating axle
 • Dual parallelogram linkage
 • Proportional boom and drive control
 • Full-time oscillating chassis
 • Rough terrain, foam-filled tires

Units available for immediate rental across Saudi Arabia and the GCC

Maintained under Dayim’s preventive maintenance regime

Inspected, tested, and certified prior to dispatch

Supported by Dayim’s 24/7 service, logistics, and technical teams

Offered under short-term, long-term, or project-based contracts

Indoor/outdoor construction, maintenance, and facility works

Sites demanding low emissions and noise control

Mixed job environments with indoor/outdoor transitions

Industrial plants, stadiums, and arenas

Telecommunications, power, and infrastructure servicing

Tasks requiring extended reach with flexible power sourcing
